Heat Detector, Type E Probe Fixed Temperature

$195.00 $362.28 Save 46%

Metro & Regional Shipping Bulk Buy Available

Heat Detector, Type E Probe Fixed Temperature

$195.00 $362.28 Save 46%

5 Years Free Service

3 Year Product Warranty

Fast Delivery

30+ Years Friendly Technical Support

Installation, Service & How to Guides

The Model 1000 Type E fixed temperature heat detector Model 1000 is a stainless steel thermal probe detector suited to severe environment conditions encountered in marine, chemical, mining and transport industries.

Suitable for special applications such as freezers, kitchen range hoods, corrosive and other hazardous areas.

This heat detector is machined from a single piece of corrosion resistant 316 stainless steel, and can be ordered in a range of temperatures from as low as 60°C to 240°C (± 5%).

The suggested temperature is +20°C above the localised expected ambient temperature.

We love this fire heat detector because of its durability, physical size and amazing 3 year warranty.

Features

Resetting type heat detector
Rate compensation
Fast response
Gold plated electrical contacts
Corrosion and shock resistant
Single mount thread (M20) or
Dual mounting thread (M20 & 1/2"NPT)
Intrinsically safe

Specifications

Contacts	Norm. Open, Close on Temp Rise
Applied Voltage - AC@0.25A - DC@0.25A	32 V max. 32 V max.
Operating Current	0.25A max
Operating / Set Temp Range	+60℃ to + 240℃
Ambient Temp Range	-40℃ to + 180℃
Relative Humidity	100%
Degree of Protection	IP67
Sensitivity & Accuracy	+/- 5% or 5 degrees
